P3440 Cylinder 5 Exhaust Valve Control Circuit High GuideMechanic.Com As engines grow more advanced and efficient, the internal systems responsible for their operation have also evolved in complexity.
One key development in modern internal combustion engines is the use of cylinder deactivation systems, such as Active Fuel Management (AFM) or Displacement on Demand (DoD).
These systems help improve fuel efficiency and reduce emissions by temporarily deactivating specific engine cylinders under light-load driving conditions.
However, these intricate systems can sometimes malfunction. One such issue is represented by Diagnostic Trouble Code (DTC) P3440, which reads: “Cylinder 5 Exhaust Valve Control Circuit High.”
In this article, we will break down the meaning of the P3440 code, its symptoms, causes, how to diagnose it, and recommended repair solutions.
See Also: P3439 Cylinder 5 Exhaust Valve Control Circuit Low
P3440 Cylinder 5 Exhaust Valve Control Circuit High
What Does Code P3440 Mean?
Code P3440 is a generic powertrain code, meaning it applies to all OBD-II equipped vehicles, though specific repair steps may vary by manufacturer.
Definition: P3440 – Cylinder 5 Exhaust Valve Control Circuit High
This code indicates that the Engine Control Module (ECM) or Powertrain Control Module (PCM) has detected a high voltage signal in the exhaust valve control circuit for cylinder number 5. This circuit is part of the system that manages valve operation during cylinder deactivation.
High voltage in this context typically refers to an unexpectedly high electrical signal (usually above 4.5V to 5V), which suggests that the circuit might be shorted to power, the solenoid is stuck, or there’s a wiring issue.
How Cylinder Deactivation Works
Modern V6 and V8 engines often employ systems like AFM or DoD to save fuel during low-demand conditions. Here’s a simplified breakdown of how they work:
When the engine is under light load, the ECM signals certain cylinders to deactivate.
Solenoids, usually mounted in a Valve Lifter Oil Manifold (VLOM), are activated.
These solenoids control oil pressure to special lifters, which collapse and prevent the intake and exhaust valves from opening.
When power is needed again, the system reactivates the cylinders by resuming normal valve operation.
In the case of P3440, the ECM has determined that the control signal to the exhaust valve solenoid for cylinder 5 is higher than expected, disrupting proper cylinder management.
P3440 Cylinder 5 Exhaust Valve Control Circuit High
Symptoms of a P3440 Code
When the P3440 code is present, the vehicle may show a range of symptoms, depending on how severely the circuit is affected. Common symptoms include:
Check Engine Light (CEL) Illuminated
The CEL will likely turn on and remain illuminated until the issue is resolved.
Rough Idle
Cylinder deactivation may be impaired, causing uneven engine operation.
Decreased Fuel Economy
AFM/DoD systems improve fuel economy. If disabled, mileage may suffer.
Reduced Engine Power
A misfiring or non-functioning cylinder could reduce performance.
Ticking or Rattling Noises
Faulty solenoids or lifters might produce abnormal engine noises.
In some cases, there may be no symptoms beyond the check engine light—especially if the vehicle is not under conditions where cylinder deactivation is engaged.
P3440 Cylinder 5 Exhaust Valve Control Circuit High
Common Causes of P3440
There are several potential reasons why the exhaust valve control circuit in cylinder 5 might show a high voltage reading:
Faulty Exhaust Valve Solenoid (Cylinder 5)
If the solenoid is stuck or malfunctioning, it may draw excessive voltage.
Shorted Wiring Harness
Wiring that is shorted to power or has damaged insulation can cause high voltage readings.
Poor Electrical Connections
Corroded, bent, or loose connectors can create resistance and voltage irregularities.
Faulty VLOM (Valve Lifter Oil Manifold)
Internal failure in the VLOM assembly can disrupt oil flow and solenoid control.
Stuck Hydraulic Valve Lifter
A lifter that is not responding properly can cause unexpected electrical behavior.
ECM or PCM Malfunction
Rare, but possible—if the control module is sending incorrect voltage to the solenoid.
P3440 Cylinder 5 Exhaust Valve Control Circuit High
Diagnosing the P3440 Code
Proper diagnosis of code P3440 involves several steps, and a scan tool alone may not provide all the answers. Here’s how a mechanic (or skilled DIY technician) would approach the issue:
1. Scan and Record All DTCs
Use an OBD-II scanner to confirm the presence of P3440. Check for additional related codes (e.g., P3436, P3439), which may indicate a systemic problem in the valve control system.
2. Inspect the Wiring and Connectors
Look for signs of damage, corrosion, or oil contamination in the wiring going to the VLOM.
Inspect the harness near the intake manifold and valve cover area—these are common pinch points.
3. Test the Solenoid
Using a multimeter, measure the resistance across the solenoid terminals for cylinder 5.
Compare the resistance to factory specifications (usually around 6–10 ohms).
Test for voltage while the engine is running, using a scan tool to command the solenoid.
4. Check the Oil Condition
Low, dirty, or incorrect viscosity oil can interfere with the hydraulic function of lifters and solenoids.
Replace with manufacturer-specified oil and filter if needed.
5. Check ECM/PCM Outputs
With advanced diagnostic tools, test the ECM’s ability to command the solenoid ON and OFF.
If outputs are normal and the circuit is good, the solenoid or VLOM is likely the issue.
P3440 Cylinder 5 Exhaust Valve Control Circuit High
Fixing a P3440 Code
Once you’ve diagnosed the root cause, here are common repair procedures:
1. Repair or Replace Wiring
If damaged wires or connectors are found, repair them or replace the affected sections of the harness.
2. Replace Cylinder 5 Exhaust Valve Solenoid
If the solenoid tests out of spec or is not operating, replace it. In many vehicles, this requires removing the intake manifold.
3. Replace or Clean the VLOM
If multiple solenoids are malfunctioning or the VLOM is clogged, it may be cost-effective to replace the entire manifold assembly.
4. Change Engine Oil and Filter
Replace dirty or incorrect oil, and reset the oil life monitor if applicable.
5. Replace Faulty Lifters
If a lifter is collapsed or stuck, it must be replaced—this is typically a labor-intensive repair.
6. Reprogram or Replace the ECM (Rare)
Only consider this if all else fails and the ECM is verified to be faulty.
After completing repairs, clear the code using an OBD-II scanner and test drive the vehicle under varying conditions to ensure the issue is resolved.
P3440 Cylinder 5 Exhaust Valve Control Circuit High
Can You Drive with Code P3440?
Driving with a P3440 code is not recommended for extended periods. While the engine may still run, there are risks:
Continued misfires or valve control issues may lead to catalytic converter damage.
Long-term fuel consumption increases.
Rough idling and stalling may worsen.
Unaddressed electrical issues can lead to more significant failures.
If the vehicle is still driveable, bring it to a mechanic as soon as possible for diagnosis and repair.
Preventing P3440 in the Future
Preventative maintenance goes a long way in avoiding valve control circuit issues:
Change Engine Oil on Time: Use high-quality oil with the correct viscosity.
Inspect Engine Wiring: Periodically check for brittle, damaged, or oil-soaked wires.
Address Check Engine Lights Promptly: Early intervention can prevent further issues.
Use Manufacturer-Specified Parts: Avoid off-brand solenoids or VLOM replacements.
Conclusion
P3440: Cylinder 5 Exhaust Valve Control Circuit High is a diagnostic trouble code that points to a problem in the cylinder deactivation system—specifically an abnormally high voltage in the exhaust valve control circuit. While this issue can affect performance, fuel economy, and drivability, it is often repairable with proper diagnostics and maintenance.
Whether caused by a faulty solenoid, wiring problem, or hydraulic lifter issue, resolving the root cause of P3440 will ensure your engine runs smoothly and efficiently once again.
